| Code | Каталожный номер | Qty | Part name | Applied S/N range | ICA | В корзину |
| 1(A) | 9133126750 | 1 | PIPE; OIL,INJ PUMP TO C/BL | 198308 - | |
| 2(B) | 1096750770 | 2 | BOLT; EYE,OIL PIPE | 198308 - | |
| 2(C) | 1096750850 | 1 | BOLT; EYE,OIL PIPE | 198308 - | |
| 3(A) | 1096300830 | 2 | GASKET; EYE BOLT,OIL PIPE | 198308 - | |
| 3(B) | 1096300840 | 4 | GASKET; EYE BOLT,OIL PIPE | 198308 - | |
| 21 | 1133451051 | 1 | STAY; OIL PIPE | 198308 - | |
| 37 | 1133118400 | 1 | PIPE; OIL,FILTER TO COOLER | 198308 - | |
| 40(A) | 0500408220 | 5 | BOLT; OIL PIPE | 199004 - | |
| 40(A) | 0500408320 | 1 | BOLT; OIL PIPE | 199004 - | |
| 40(B) | 9133126751 | 2 | BOLT; OIL PIPE | 199004 - | |
| 44 | 0501408200 | 1 | BOLT; CLIP,OIL PIPE | 199004 - | |
| 47 | 1096234500 | 2 | GASKET; OIL PIPE | 199004 - | |
| 48 | 1097003320 | 1 | CLIP; OIL PIPE | 198308 - | |
| 54(B) | 1133451460 | 1 | STAY; OIL STRAINER | 198709 - | |
| 54(D) | 1133451470 | 1 | STAY; OIL STRAINER | 198709 - | |
| 62 | 1133117041 | 1 | PIPE; OIL,PUMP TO C/BL | 198308 - | |
| 63 | 1133124620 | 1 | PIPE; OIL,TURBOCHARGER FEED | 198308 - | |
| 72(A) | 9091505100 | 1 | WASHER; LK,OIL PIPE | 198308 - | |
| 72(B) | 9091505080 | 2 | WASHER; LK,OIL PIPE | 198308 - | |
| 74 | 9091104080 | 1 | NUT; CLIP,OIL PIPE,PUMP TO BODY | 198308 - | |
| 76 | 9091606080 | 1 | WASHER; CLIP | 198308 - | |
| 77 | 0500408160 | 1 | BOLT; STAY,PUMP TO BODY | 199004 - | |
| 78(A) | 0168060550 | 1 | BOLT; OIL PIPE,PUMP TO BODY | 199004 - | |
| 78(A) | 0500510220 | 1 | BOLT; OIL PIPE,PUMP TO BODY | 199004 - | |
| 78(B) | 0108058700 | 2 | BOLT; OIL PIPE,PUMP TO BODY | 199004 - | |
| 81 | 0500408350 | 2 | BOLT; OIL PIPE,BODY TO BODY | 199004 - | |
| 84 | 9098440220 | 1 | NUT; CAP,OIL PIPE | 198308 - | |
| 90(A) | 9133125081 | 1 | PIPE ASM; OIL,C/BL TO FILTER | 198308 - 199807 | |
| 90(B) | 1133122860 | 1 | PIPE ASM; OIL,C/BL TO FILTER | 199808 - | |
| 91(A) | 9133126752 | 3 | BOLT; OIL PIPE,BODY TO FILTER | 199004 - | |
| 91(A) | 0500408400 | 1 | BOLT; OIL PIPE,BODY TO FILTER | 199004 - | |
| 99 | 1097006340 | 1 | CLIP; OIL PIPE,FILTER TO COOLER | 198308 - | |
| 100 | 0500410200 | 1 | BOLT; CLIP | 199004 - | |
| 101 | 1133451180 | 1 | BRACKET; CLIP | 198308 - | |
| 102 | 0238014250 | 1 | BOLT; BRKT | 199004 - | |
| 103 | 9091505140 | 1 | WASHER; LK,BRKT | 198308 - | |
| 104(A) | 1133113041 | 1 | PIPE ASM; OIL,COOLER TO BODY | 198308 - 199807 | |
| 104(B) | 1133123430 | 1 | PIPE ASM; OIL,COOLER TO BODY | 199808 - | |
| 105 | 9133126753 | 4 | GASKET; OIL PIPE,COOLER TO BODY | 199004 - | |
| 106(A) | 9133126754 | 2 | BOLT; OIL PIPE,COOLER TO BODY | 199004 - | |
| 109(B) | 1133126390 | 1 | PIPE ASM; OIL,BODY TO HD | 198607 - | |
| 110 | 9098446321 | 1 | NUT; CAP OIL PIPE | 198607 - | |
| 111(A) | 9133126755 | 4 | GASKET; JOINT,OIL PIPE,BODY TO HD | 198607 - | |
| 111(B) | 9133126756 | 2 | GASKET; JOINT,OIL PIPE,BODY TO HD | 198607 - | |
| 112 | 1097001440 | 1 | CLIP; OIL PIPE,TAP CHAMBER CVR | 198308 - | |
| 113 | 1097004440 | 1 | CLIP; WATER OUTLET PIPE | 198308 - | |
| 114 | 1133117031 | 1 | PIPE ASM; OIL,BODY | 198308 - | |
| 115 | 9099176490 | 1 | CLIP; PIPE,INJ PUMP | 199402 - | |
| 132 | 9133124141 | 1 | PIPE ASM; OIL,INJ PUMP FEED | 198308 - | |
| 145 | 9133126757 | 1 | NUT; CAP,OIL PIPE,TURBOCHARGER FEED | 198308 - | |
| 147(A) | 1096232740 | 1 | GASKET; OIL PIPE TO TURBOCHARGER | 198308 - | |
| 147(B) | 1096233590 | 1 | GASKET; OIL PIPE TO TURBOCHARGER | 198308 - | |
| 149 | 1133126130 | 1 | PIPE; OIL RETURN,TURBOCHARGER | 198308 - | |
| 150 | 1096232970 | 1 | GASKET; OIL PIPE TO C/BL | 198308 - | |
| 151 | 9133126758 | 2 | NUT; PIPE,TURBOCHARGER RETAINER | 198308 - | |
| 152 | 9133126759 | 2 | WASHER; LK,OIL PIPE,TURBOCHARGER | 198308 - | |
| 222 | 1132600611 | 1 | VALVE ASM; CHECK | 198308 - | |
| 357 | 5095031110 | 4 | WASHER; PL,STAY | 198308 - | |
| 371 | 9133126760 | 4 | BOLT; STAY | 199004 - | |
